0ZCK0100FF2E
PTC RESET FUSE 6V 1A 0805
Manufacturer: Bel Fuse Inc.IC code: 5923-0ZCK0100FF2ETR-ND - Tape & Reel (TR) || 5923-0ZCK0100FF2ECT-ND - Cut Tape (CT) || 5923-0ZCK0100FF2EDKR-ND - Digi-Reel® Request this MPN now. Sourcing more than one part? Upload your BOM and we can consolidate component sourcing into one quotation.
Description
Polymeric PTC Resettable Fuse 6V 1 A Ih Surface Mount 0805 (2012 Metric), Concave
Specifications
- Type
- Polymeric
- Grade
- Automotive
- Series
- 0ZCK
- Ratings
- -
- Packaging
- Tape & Reel (TR) || Cut Tape (CT) || Digi-Reel®
- Part Status
- Active
- Lead Spacing
- -
- Manufacturer
- Bel Fuse Inc.
- Time to Trip
- 300 ms
- Current - Max
- 40 A
- Mounting Type
- Surface Mount
- Qualification
- AEC-Q200
- Voltage - Max
- 6V
Approval AgencycURus, TUV Thickness (Max)0.071" (1.80mm) Size / Dimension0.085" L x 0.053" W (2.15mm x 1.35mm) Current - Trip (It)1.95 A Operating Temperature-40°C ~ 85°C Current - Hold (Ih) (Max)1 A Resistance - Initial (Ri) (Min)60 mOhms Resistance - Post Trip (R1) (Max)210 mOhms Pricing tiers
| Packaging | Qty | Unit price |
|---|
| Cut Tape (CT) & Digi-Reel® | 1 | ¥3.64000 |
| Cut Tape (CT) & Digi-Reel® | 5 | ¥3.02600 |
| Cut Tape (CT) & Digi-Reel® | 10 | ¥2.78700 |
| Cut Tape (CT) & Digi-Reel® | 50 | ¥2.31400 |
| Cut Tape (CT) & Digi-Reel® | 100 | ¥2.13530 |
| Cut Tape (CT) & Digi-Reel® | 250 | ¥1.91964 |
| Cut Tape (CT) & Digi-Reel® | 500 | ¥1.77078 |
| Cut Tape (CT) & Digi-Reel® | 1,000 | ¥1.63307 |
| Tape & Reel (TR) | 3,000 | ¥1.43528 |
| Tape & Reel (TR) | 6,000 | ¥1.32214 |
| Tape & Reel (TR) | 9,000 | ¥1.25979 |
| Tape & Reel (TR) | 15,000 | ¥1.18500 |
| Tape & Reel (TR) | 21,000 | ¥1.16100 |
