Request this MPN now. Sourcing more than one part? Upload your BOM and we can consolidate component sourcing into one quotation.
Description
Connector Header Through Hole 32 (26 + 6 Power) position
Specifications
- Mfr
- HARTING
- Style
- Board to Cable/Wire
- Series
- har-flex®
- Features
- Board Guide, Solder Retention
- Packaging
- Bulk
- Shrouding
- Shrouded - 4 Wall
- Part Status
- Active
- Termination
- Solder
- Applications
- General Purpose
- Contact Type
- Male Pin
- Contact Shape
- Rectangular
- Mounting Type
- Through Hole
- Connector Type
- Header
Voltage Rating50VAC, 125VDC Contact MaterialCopper Alloy Insulation Height0.319" (8.10mm) Insulation MaterialLiquid Crystal Polymer (LCP) Number of Positions32 (26 + 6 Power) Row Spacing - Mating0.050" (1.27mm) Contact Length - Post0.098" (2.50mm) Current Rating (Amps)21.5A Operating Temperature-55°C ~ 125°C Contact Finish - MatingGold Number of Positions LoadedAll Material Flammability RatingUL94 V-0 Contact Finish Thickness - Post- Contact Finish Thickness - Mating- Pricing tiers
| Packaging | Qty | Unit price |
|---|
| Bulk | 400 | ¥7,824.10648 |
