Request this MPN now. Sourcing more than one part? Upload your BOM and we can consolidate component sourcing into one quotation.
Description
Connector Header Through Hole 16 position 0.118" (3.00mm)
Specifications
- Mfr
- Molex
- Style
- Board to Cable/Wire
- Series
- Micro-Fit+ 206832
- Features
- Board Guide, Glow Wire Compliant
- Packaging
- Tray
- Shrouding
- Shrouded - 4 Wall
- Part Status
- Active
- Termination
- Solder
- Applications
- -
- Contact Type
- Male Pin
- Contact Shape
- Square
- Mounting Type
- Through Hole
- Connector Type
- Header
Pitch - Mating0.118" (3.00mm) Contact MaterialCopper Alloy Insulation Height0.390" (9.91mm) Base Product Number206832 Insulation MaterialLiquid Crystal Polymer (LCP), Glass Filled Row Spacing - Mating0.118" (3.00mm) Contact Length - Post0.125" (3.18mm) Current Rating (Amps)Varies by Wire Gauge Operating Temperature-40°C ~ 105°C Contact Finish - MatingGold Number of Positions LoadedAll Material Flammability RatingUL94 V-0 Contact Finish Thickness - Post- Contact Finish Thickness - Mating15.0µin (0.38µm) Pricing tiers
| Packaging | Qty | Unit price |
|---|
| Tray | 1 | ¥49.70000 |
| Tray | 78 | ¥36.55128 |
| Tray | 156 | ¥34.80603 |
| Tray | 546 | ¥31.86264 |
| Tray | 1,014 | ¥30.50199 |
