37532
TRANSF QUAD T1/E1 1:1.36CT SMD
Manufacturer: Schott CorporationIC code: 257-1128-2-ND - Tape & Reel (TR) || 257-1128-1-ND - Cut Tape (CT)
Request this MPN now. Sourcing more than one part? Upload your BOM and we can consolidate component sourcing into one quotation.
Description
1.2mH T1/E1 (Quad) Pulse Transformer 1:1.36CT Surface Mount
Specifications
- Series
- -
- Weight
- -
- Packaging
- Tape & Reel (TR) || Cut Tape (CT)
- Inductance
- 1.2mH
- Part Status
- Discontinued at Digi-Key
- Manufacturer
- Schott Corporation
- Mounting Type
- Surface Mount
- ET (Volt-Time)
- -
- Size / Dimension
- 1.000" L x 0.300" W (25.40mm x 7.62mm)
- Transformer Type
- T1/E1 (Quad)
- Height - Seated (Max)
- 0.290" (7.37mm)
- Operating Temperature
- -
- Turns Ratio - Primary:Secondary
