59242-0040N-001
4 POS, 3.0 MM PITCH MICRO FIT HE
Manufacturer: Aces ConnectorsIC code: 4294-59242-0040N-001TR-ND - Tape & Reel (TR) || 4294-59242-0040N-001CT-ND - Cut Tape (CT) || 4294-59242-0040N-001DKR-ND - Digi-Reel® Request this MPN now. Sourcing more than one part? Upload your BOM and we can consolidate component sourcing into one quotation.
Description
Connector Header Surface Mount, Right Angle 4 position 0.118" (3.00mm)
Specifications
- Mfr
- Aces Connectors
- Style
- Board to Cable/Wire
- Series
- 59242
- Features
- Solder Retention
- Packaging
- Tape & Reel (TR) || Cut Tape (CT) || Digi-Reel®
- Shrouding
- Shrouded - 4 Wall
- Part Status
- Active
- Termination
- Solder
- Applications
- General Purpose
- Contact Type
- Male Pin
- Contact Shape
- Square
- Mounting Type
- Surface Mount, Right Angle
- Connector Type
Fastening TypeLocking Ramp Pitch - Mating0.118" (3.00mm) Contact MaterialCopper Alloy Insulation Height0.346" (8.80mm) Insulation MaterialThermoplastic Row Spacing - Mating0.118" (3.00mm) Current Rating (Amps)12.5A Operating Temperature-40°C ~ 105°C Contact Finish - MatingTin Number of Positions LoadedAll Material Flammability RatingUL94 V-0 Contact Finish Thickness - Post- Contact Finish Thickness - Mating- Pricing tiers
| Packaging | Qty | Unit price |
|---|
| Cut Tape (CT) & Digi-Reel® | 1 | ¥15.55000 |
| Cut Tape (CT) & Digi-Reel® | 10 | ¥13.23900 |
| Cut Tape (CT) & Digi-Reel® | 25 | ¥12.41040 |
| Cut Tape (CT) & Digi-Reel® | 50 | ¥11.81680 |
| Cut Tape (CT) & Digi-Reel® | 100 | ¥11.25210 |
| Tape & Reel (TR) | 250 | ¥10.54700 |
| Tape & Reel (TR) | 500 | ¥10.04342 |
| Tape & Reel (TR) | 750 | ¥9.76021 |
| Tape & Reel (TR) | 1,250 | ¥9.41478 |
| Tape & Reel (TR) | 1,750 | ¥9.19397 |
| Tape & Reel (TR) | 2,500 | ¥8.96562 |
| Tape & Reel (TR) | 6,250 | ¥8.40487 |
