Request this MPN now. Sourcing more than one part? Upload your BOM and we can consolidate component sourcing into one quotation.
Description
Connector Header Through Hole, Right Angle 16 position 0.100" (2.54mm)
Specifications
- Mfr
- TE Connectivity AMP Connectors
- Style
- Board to Board or Cable
- Series
- AMPMODU Mod II
- Features
- -
- Packaging
- Bulk
- Shrouding
- Unshrouded
- Part Status
- Active
- Termination
- Solder
- Applications
- -
- Contact Type
- Male Pin
- Contact Shape
- Square
- Mounting Type
- Through Hole, Right Angle
- Connector Type
- Header, Breakaway
Pitch - Mating0.100" (2.54mm) Insulation Height0.219" (5.56mm) Base Product Number826664 Insulation MaterialPolybutylene Terephthalate (PBT) Row Spacing - Mating0.100" (2.54mm) Contact Length - Post0.126" (3.20mm) Operating Temperature-65°C ~ 105°C Contact Finish - MatingGold Contact Length - Mating0.315" (8.00mm) Number of Positions LoadedAll Material Flammability RatingUL94 V-0 Contact Finish Thickness - Post118.1µin (3.00µm) Contact Finish Thickness - Mating3.90µin (0.099µm) Pricing tiers
| Packaging | Qty | Unit price |
|---|
| Bulk | 1 | ¥23.07000 |
| Bulk | 10 | ¥19.63300 |
| Bulk | 300 | ¥15.44173 |
| Bulk | 600 | ¥14.70473 |
| Bulk | 1,200 | ¥14.00316 |
| Bulk | 5,100 | ¥12.64540 |
