Description
Connector Header Through Hole 4 position 0.025" (0.64mm)
Specifications
- Mfr
- Omnetics
- Style
- Board to Cable/Wire
- Series
- Polarized Nano
- Features
- -
- Packaging
- Bag
- Shrouding
- -
- Part Status
- Active
- Termination
- Solder
- Applications
- -
- Contact Type
- Female Socket; Male Pin
- Contact Shape
- Circular
- Mounting Type
- Through Hole
- Connector Type
- Header
- Fastening Type
Pitch - Mating0.025" (0.64mm) Contact MaterialBeryllium Copper Insulation Height0.170" (4.32mm) Insulation MaterialThermoplastic Row Spacing - Mating0.040" (1.02mm) Contact Finish - PostTin-Lead Contact Length - Post0.100" (2.54mm) Current Rating (Amps)1A per Contact Operating Temperature-55°C ~ 125°C Contact Finish - MatingGold Contact Length - Mating0.060" (1.52mm) Number of Positions LoadedAll Material Flammability Rating- Contact Finish Thickness - Post- Contact Finish Thickness - Mating50.0µin (1.27µm) Pricing tiers
| Packaging | Qty | Unit price |
|---|
| Bag | 1 | ¥368.54000 |
| Bag | 10 | ¥313.22500 |
| Bag | 100 | ¥266.27960 |
