ACM2004G-FL-YBW-R
20 X 4 CHARACTER MONOCHROME
Manufacturer: AZ DisplaysIC code: 2470-ACM2004G-FL-YBW-R-ND
Request this MPN now. Sourcing more than one part? Upload your BOM and we can consolidate component sourcing into one quotation.
Description
Character Display Module Transflective 5 x 8 Dots STN - Super-Twisted Nematic LED - Yellow/Green 98.00mm x 60.00mm x 14.20mm
Specifications
- Series
- -
- Dot Size
- 0.55mm W x 0.55mm H
- Backlight
- LED - Yellow/Green
- Interface
- -
- Packaging
- Box
- Text Color
- -
- Part Status
- Active
- Display Mode
- Transflective
- Display Type
- STN - Super-Twisted Nematic
- Manufacturer
- AZ Displays
- Viewing Area
- 76.00mm L x 25.20mm W
- Character Size
- 4.75mm H x 2.95mm W
- Display Format
- 20 x 4
- Controller Type
- ST7066U-0A
- Background Color
- -
- Character Format
- 5 x 8 Dots
- Voltage - Supply
- 4.8V ~ 5.2V
- Outline L x W x H
- 98.00mm x 60.00mm x 14.20mm
