Description
General Purpose Relay SPDT (1 Form C) 24VDC Coil Through Hole
Specifications
- Mfr
- American Zettler
- Grade
- -
- Series
- AZ576
- Features
- -
- Coil Type
- Non Latching
- Packaging
- Tube
- Relay Type
- General Purpose
- Part Status
- Active
- Seal Rating
- Sealed - Fully
- Coil Current
- 16.7 mA
- Coil Voltage
- 24VDC
- Contact Form
- SPDT (1 Form C)
- Operate Time
- 15 ms
- Release Time
Mounting TypeThrough Hole Approval AgencyCUR, TUV, UL Coil Resistance1.44 kOhms Contact MaterialSilver Tin Oxide (AgSnO) Switching Voltage480VAC, 30VDC - Max Base Product NumberAZ576-1C Load - Max Switching5540VA, 510W Must Operate Voltage18 VDC Must Release Voltage2.4 VDC Operating Temperature-40°C ~ 105°C Contact Rating (Current)20 A Pricing tiers
| Packaging | Qty | Unit price |
|---|
| Tube | 1 | ¥27.04000 |
| Tube | 20 | ¥23.30550 |
| Tube | 40 | ¥22.50825 |
| Tube | 60 | ¥22.05383 |
| Tube | 100 | ¥21.49530 |
| Tube | 260 | ¥20.48562 |
| Tube | 500 | ¥19.82152 |
| Tube | 1,000 | ¥19.14067 |
| Tube | 5,000 | ¥17.64722 |
