Description
General Purpose Relay SPST-NO (1 Form A) 24VDC Coil Through Hole
Specifications
- Mfr
- American Zettler
- Grade
- -
- Series
- AZ7621
- Features
- -
- Coil Type
- Non Latching
- Packaging
- Box
- Relay Type
- General Purpose
- Part Status
- Active
- Seal Rating
- Sealed - Fully
- Coil Current
- 17.1 mA
- Coil Voltage
- 24VDC
- Contact Form
- SPST-NO (1 Form A)
- Operate Time
- 7 ms
- Release Time
Mounting TypeThrough Hole Approval AgencyCUR, TUV, UL Coil Resistance1.405 kOhms Contact MaterialSilver Tin Oxide (AgSnO) Switching Voltage440VAC, 125VDC - Max Base Product NumberAZ7621-1A Load - Max Switching4000VA, 480W Must Operate Voltage16.8 VDC Must Release Voltage2.4 VDC Operating Temperature-40°C ~ 85°C Contact Rating (Current)16 A Pricing tiers
| Packaging | Qty | Unit price |
|---|
| Box | 1 | ¥17.34000 |
| Box | 20 | ¥14.93200 |
| Box | 40 | ¥14.42000 |
| Box | 60 | ¥14.12800 |
| Box | 100 | ¥13.77050 |
| Box | 260 | ¥13.12423 |
| Box | 500 | ¥12.69900 |
| Box | 1,000 | ¥12.26307 |
| Box | 5,000 | ¥11.30667 |
