BG301-04-A-0540-L-B
CONN HEADER SMD R/A 4POS 2.54MM
Manufacturer: GCTIC code: 2073-BG301-04-A-0540-L-BTR-ND - Tape & Reel (TR) || 2073-BG301-04-A-0540-L-BCT-ND - Cut Tape (CT) || 2073-BG301-04-A-0540-L-BDKR-ND - Digi-Reel® Request this MPN now. Sourcing more than one part? Upload your BOM and we can consolidate component sourcing into one quotation.
Description
Connector Header Surface Mount, Right Angle 4 position 0.100" (2.54mm)
Specifications
- Mfr
- GCT
- Style
- Board to Board
- Series
- BG301
- Features
- Pick and Place
- Packaging
- Tape & Reel (TR) || Cut Tape (CT) || Digi-Reel®
- Shrouding
- Unshrouded
- Part Status
- Active
- Termination
- Solder
- Applications
- General Purpose
- Contact Type
- Male Pin
- Contact Shape
- Square
- Mounting Type
- Surface Mount, Right Angle
- Connector Type
- Header, Cuttable
Pitch - Mating0.100" (2.54mm) Contact MaterialCopper Alloy Insulation Height0.098" (2.50mm) Insulation MaterialLiquid Crystal Polymer (LCP), Glass Filled Contact Finish - PostGold Current Rating (Amps)3A per Contact Operating Temperature-40°C ~ 105°C Contact Finish - MatingGold Contact Length - Mating0.213" (5.40mm) Number of Positions LoadedAll Material Flammability RatingUL94 V-0 Contact Finish Thickness - PostFlash Contact Finish Thickness - MatingFlash Pricing tiers
| Packaging | Qty | Unit price |
|---|
| Cut Tape (CT) & Digi-Reel® | 1 | ¥5.13000 |
| Cut Tape (CT) & Digi-Reel® | 10 | ¥4.37500 |
| Cut Tape (CT) & Digi-Reel® | 100 | ¥3.71740 |
| Cut Tape (CT) & Digi-Reel® | 500 | ¥3.31742 |
| Tape & Reel (TR) | 1,000 | ¥3.15897 |
| Tape & Reel (TR) | 2,000 | ¥3.00817 |
| Tape & Reel (TR) | 3,000 | ¥2.92330 |
| Tape & Reel (TR) | 5,000 | ¥2.81985 |
| Tape & Reel (TR) | 7,000 | ¥2.75372 |
| Tape & Reel (TR) | 10,000 | ¥2.68532 |
| Tape & Reel (TR) | 25,000 | ¥2.51735 |
