Request this MPN now. Sourcing more than one part? Upload your BOM and we can consolidate component sourcing into one quotation.
Description
Connector Header Through Hole 14 position 0.100" (2.54mm)
Specifications
- Mfr
- Cvilux USA
- Style
- Board to Board or Cable
- Series
- CH87
- Features
- -
- Packaging
- Tray
- Shrouding
- Shrouded - 4 Wall
- Part Status
- Active
- Termination
- Solder
- Applications
- -
- Contact Type
- Male Pin
- Contact Shape
- Square
- Mounting Type
- Through Hole
- Connector Type
- Header
- Fastening Type
Pitch - Mating0.100" (2.54mm) Insulation Height0.358" (9.10mm) Insulation MaterialPolybutylene Terephthalate (PBT) Row Spacing - Mating0.100" (2.54mm) Contact Finish - PostGold Contact Length - Post0.110" (2.80mm) Operating Temperature-40°C ~ 105°C Contact Finish - MatingGold Number of Positions LoadedAll Material Flammability RatingUL94 V-0 Contact Finish Thickness - PostFlash Contact Finish Thickness - MatingFlash Pricing tiers
| Packaging | Qty | Unit price |
|---|
| Tray | 1 | ¥1.98000 |
| Tray | 10 | ¥1.69500 |
| Tray | 200 | ¥1.37240 |
| Tray | 600 | ¥1.27000 |
| Tray | 1,000 | ¥1.22495 |
| Tray | 5,000 | ¥1.09336 |
| Tray | 10,000 | ¥1.04117 |
