CI0103M1VR0-NH
3 POS 2.00MM(.079) SINGLE ROW SM
Manufacturer: Cvilux USAIC code: 2987-CI0103M1VR0-NHTR-ND - Tape & Reel (TR) || 2987-CI0103M1VR0-NHCT-ND - Cut Tape (CT) Request this MPN now. Sourcing more than one part? Upload your BOM and we can consolidate component sourcing into one quotation.
Description
Connector Header Surface Mount 3 position 0.079" (2.00mm)
Specifications
- Mfr
- Cvilux USA
- Style
- Board to Cable/Wire
- Series
- CI01
- Features
- Pick and Place, Solder Retention
- Packaging
- Tape & Reel (TR) || Cut Tape (CT)
- Shrouding
- Shrouded - 4 Wall
- Part Status
- Active
- Termination
- Solder
- Applications
- -
- Contact Type
- Male Pin
- Contact Shape
- Square
- Mounting Type
- Surface Mount
- Connector Type
- Header
Fastening TypeDetent Lock Pitch - Mating0.079" (2.00mm) Insulation Height0.263" (6.67mm) Base Product NumberCI0103M1 Insulation MaterialPolyamide (PA6T), Nylon 6T, Halogen Free Operating Temperature-25°C ~ 105°C Contact Finish - MatingTin Contact Length - Mating0.142" (3.61mm) Number of Positions LoadedAll Material Flammability RatingUL94 V-0 Contact Finish Thickness - Post120.0µin (3.05µm) Contact Finish Thickness - Mating120.0µin (3.05µm) Pricing tiers
| Packaging | Qty | Unit price |
|---|
| Cut Tape (CT) | 1 | ¥2.32000 |
| Cut Tape (CT) | 10 | ¥1.94300 |
| Cut Tape (CT) | 100 | ¥1.64990 |
| Tape & Reel (TR) | 500 | ¥1.47272 |
| Tape & Reel (TR) | 1,000 | ¥1.40226 |
| Tape & Reel (TR) | 1,500 | ¥1.36267 |
| Tape & Reel (TR) | 2,500 | ¥1.31440 |
| Tape & Reel (TR) | 3,500 | ¥1.28353 |
| Tape & Reel (TR) | 5,000 | ¥1.25163 |
| Tape & Reel (TR) | 12,500 | ¥1.17326 |
| Tape & Reel (TR) | 25,000 | ¥1.11728 |
| Tape & Reel (TR) | 50,000 | ¥1.06400 |
