CI1503M1HR0-NH
3 POS 1.50MM(.059) WIRE TO BOARD
Manufacturer: Cvilux USAIC code: 2987-CI1503M1HR0-NHTR-ND - Tape & Reel (TR) || 2987-CI1503M1HR0-NHCT-ND - Cut Tape (CT) Request this MPN now. Sourcing more than one part? Upload your BOM and we can consolidate component sourcing into one quotation.
Description
Connector Header Surface Mount, Right Angle 3 position 0.059" (1.50mm)
Specifications
- Mfr
- Cvilux USA
- Style
- Board to Cable/Wire
- Series
- CI15
- Features
- Solder Retention
- Packaging
- Tape & Reel (TR) || Cut Tape (CT)
- Shrouding
- Shrouded - 4 Wall
- Part Status
- Active
- Termination
- Solder
- Applications
- -
- Contact Type
- Male Pin
- Contact Shape
- Square
- Mounting Type
- Surface Mount, Right Angle
- Connector Type
- Header
Fastening TypeDetent Lock Pitch - Mating0.059" (1.50mm) Insulation Height0.148" (3.75mm) Base Product NumberCI1503M1 Insulation MaterialPolyamide (PA46), Nylon 4/6 Current Rating (Amps)1A (AC/DC) Operating Temperature-25°C ~ 85°C Contact Finish - MatingTin Contact Length - Mating0.100" (2.54mm) Number of Positions LoadedAll Material Flammability RatingUL94 V-0 Contact Finish Thickness - Post120.0µin (3.05µm) Contact Finish Thickness - Mating120.0µin (3.05µm) Pricing tiers
| Packaging | Qty | Unit price |
|---|
| Cut Tape (CT) | 1 | ¥1.57000 |
| Cut Tape (CT) | 10 | ¥1.36500 |
| Cut Tape (CT) | 100 | ¥1.16110 |
| Cut Tape (CT) | 500 | ¥1.03606 |
| Tape & Reel (TR) | 1,400 | ¥0.96014 |
| Tape & Reel (TR) | 2,800 | ¥0.91428 |
| Tape & Reel (TR) | 4,200 | ¥0.88849 |
| Tape & Reel (TR) | 7,000 | ¥0.85702 |
| Tape & Reel (TR) | 9,800 | ¥0.83690 |
| Tape & Reel (TR) | 14,000 | ¥0.81611 |
| Tape & Reel (TR) | 35,000 | ¥0.76502 |
| Tape & Reel (TR) | 70,000 | ¥0.72853 |
