Description
Connector Header Through Hole 2 position
Specifications
- Mfr
- Cvilux USA
- Style
- Board to Cable/Wire
- Series
- CP35
- Features
- Board Guide
- Packaging
- Tray
- Shrouding
- Shrouded - 4 Wall
- Part Status
- Active
- Termination
- Kinked Pin, Solder
- Applications
- -
- Contact Type
- Male Pin
- Contact Shape
- Square
- Mounting Type
- Through Hole
- Connector Type
- Header
Insulation Height0.390" (9.91mm) Base Product NumberCP3502P1 Insulation MaterialThermoplastic Row Spacing - Mating0.118" (3.00mm) Contact Length - Post0.126" (3.20mm) Operating Temperature-40°C ~ 105°C Contact Finish - MatingTin Number of Positions LoadedAll Material Flammability Rating- Contact Finish Thickness - Post- Contact Finish Thickness - Mating- Pricing tiers
| Packaging | Qty | Unit price |
|---|
| Tray | 1 | ¥2.48000 |
| Tray | 10 | ¥2.08400 |
| Tray | 120 | ¥1.74842 |
| Tray | 600 | ¥1.56042 |
| Tray | 1,080 | ¥1.49694 |
| Tray | 5,040 | ¥1.34267 |
| Tray | 10,080 | ¥1.27859 |
