Request this MPN now. Sourcing more than one part? Upload your BOM and we can consolidate component sourcing into one quotation.
Description
Fan Tubeaxial 24VDC Square - 120mm L x 120mm H Ball 138.0 CFM (3.86m³/min) 3 Wire Leads
Specifications
- Mfr
- Sunon Fans
- RPM
- 3100 RPM
- Noise
- 48.0dB(A)
- Width
- 38.00mm
- Series
- EEC
- Weight
- 0.472 lb (214.1 g)
- Air Flow
- 138.0 CFM (3.86m³/min)
- Fan Type
- Tubeaxial
- Features
- Auto Restart, Locked Rotor Sensor
- Packaging
- Box
- Part Status
- Last Time Buy
- Termination
- 3 Wire Leads
- Bearing Type
- Ball
Voltage Range10 ~ 27.6VDC Approval AgencyCE, CUR, TUV, UL Static Pressure0.360 in H2O (89.6 Pa) Lifetime @ Temp.70000 Hrs @ 40°C Material - BladePolybutylene Terephthalate (PBT) Material - FramePolybutylene Terephthalate (PBT) Size / DimensionSquare - 120mm L x 120mm H Base Product NumberEEC0382B1 Current Rating (Amps)0.383A Operating Temperature14 ~ 158°F (-10 ~ 70°C) Pricing tiers
| Packaging | Qty | Unit price |
|---|
| Box | 1 | ¥193.37000 |
| Box | 10 | ¥158.43200 |
| Box | 40 | ¥138.75725 |
| Box | 80 | ¥133.39713 |
