IMC0805ERR22J
FIXED IND 220NH 170MA 1.41OHM SM
Manufacturer: Vishay DaleIC code: IMC0805ERR22J-ND - Tape & Reel (TR)
Request this MPN now. Sourcing more than one part? Upload your BOM and we can consolidate component sourcing into one quotation.
Description
220 nH Unshielded Wirewound Inductor 170 mA 1.41Ohm Max 0805 (2012 Metric)
Specifications
- Mfr
- Vishay Dale
- Type
- Wirewound
- Series
- IMC-0805
- Ratings
- -
- Q @ Freq
- 10 @ 25.2MHz
- Packaging
- Tape & Reel (TR)
- Shielding
- Unshielded
- Tolerance
- ±5%
- Inductance
- 220 nH
- Part Status
- Obsolete
- Mounting Type
- Surface Mount
- Package / Case
- 0805 (2012 Metric)
- Material - Core
- Non-Magnetic
- Size / Dimension
- 0.079" L x 0.049" W (2.00mm x 1.25mm)
- DC Resistance (DCR)
- 1.41Ohm Max
- Current Rating (Amps)
- 170 mA
- Height - Seated (Max)
- 0.061" (1.55mm)
- Operating Temperature
- -40°C ~ 105°C
