Request this MPN now. Sourcing more than one part? Upload your BOM and we can consolidate component sourcing into one quotation.
Description
General Purpose Relay SPST-NO (1 Form A) 48VDC Coil Chassis Mount
Specifications
- Mfr
- CIT Relay and Switch
- Grade
- -
- Series
- J167
- Features
- -
- Coil Type
- Non Latching
- Packaging
- Tray
- Relay Type
- General Purpose
- Part Status
- Active
- Seal Rating
- -
- Coil Current
- 39.3 mA
- Coil Voltage
- 48VDC
- Contact Form
- SPST-NO (1 Form A)
- Operate Time
- 30 ms
- Release Time
Mounting TypeChassis Mount Approval AgencycURus, TUV Coil Resistance1.22 kOhms Contact MaterialSilver Tin Oxide Indium Oxide (AgSnOInO) Switching Voltage277VAC, 30VDC - Max Termination StyleQuick Connect - 0.250" (6.3mm) Load - Max Switching6600VA Must Operate Voltage33.6 VDC Must Release Voltage4.8 VDC Operating Temperature-40°C ~ 85°C Contact Rating (Current)30 A Pricing tiers
| Packaging | Qty | Unit price |
|---|
| Tray | 10 | ¥101.06600 |
