LS75C2D7
SWITCH TACTILE SPST-NO 0.02A 12V
Manufacturer: CitizenIC code: 1642-LS75C2D7TR-ND - Tape & Reel (TR) || 1642-LS75C2D7CT-ND - Cut Tape (CT) || 1642-LS75C2D7DKR-ND - Digi-Reel® Request this MPN now. Sourcing more than one part? Upload your BOM and we can consolidate component sourcing into one quotation.
Description
Tactile Switch SPST-NO Top Actuated
Specifications
- Mfr
- Citizen
- Series
- LS75
- Circuit
- SPST-NO
- Outline
- 2.80mm x 1.90mm
- Features
- -
- Packaging
- Tape & Reel (TR) || Cut Tape (CT) || Digi-Reel®
- Part Status
- Active
- Illumination
- Non-Illuminated
- Actuator Type
- Standard
- Switch Travel
- 0.15mm
- Mechanical Life
- 300,000 Cycles
- Operating Force
- 163gf
- Switch Function
- Off-Mom
Termination StyleSMD (SMT) Tab Ingress ProtectionIP67 - Dust Tight, Waterproof Base Product NumberLS75C2 Actuator OrientationTop Actuated Contact Rating @ Voltage0.02A @ 12VDC Illumination Type, Color- Actuator Length, Right Angle- Illumination Voltage (Nominal)- Actuator Height off PCB, Vertical0.50mm Pricing tiers
| Packaging | Qty | Unit price |
|---|
| Cut Tape (CT) & Digi-Reel® | 1 | ¥2.98000 |
| Cut Tape (CT) & Digi-Reel® | 10 | ¥2.58000 |
| Cut Tape (CT) & Digi-Reel® | 25 | ¥2.41160 |
| Cut Tape (CT) & Digi-Reel® | 100 | ¥2.15930 |
| Cut Tape (CT) & Digi-Reel® | 250 | ¥2.00036 |
| Cut Tape (CT) & Digi-Reel® | 500 | ¥1.88788 |
| Cut Tape (CT) & Digi-Reel® | 1,000 | ¥1.78284 |
| Cut Tape (CT) & Digi-Reel® | 2,500 | ¥1.65681 |
| Tape & Reel (TR) | 5,000 | ¥1.72884 |
| Tape & Reel (TR) | 10,000 | ¥1.64489 |
| Tape & Reel (TR) | 15,000 | ¥1.60013 |
| Tape & Reel (TR) | 25,000 | ¥1.54821 |
| Tape & Reel (TR) | 35,000 | ¥1.51661 |
| Tape & Reel (TR) | 50,000 | ¥1.48527 |
