Request this MPN now. Sourcing more than one part? Upload your BOM and we can consolidate component sourcing into one quotation.
Description
Connector Header Through Hole 7 position 0.049" (1.25mm)
Specifications
- Mfr
- Harwin Inc.
- Style
- Board to Cable/Wire
- Series
- M30
- Features
- -
- Packaging
- Bulk
- Shrouding
- Shrouded - 4 Wall
- Part Status
- Obsolete
- Termination
- Solder
- Applications
- -
- Contact Type
- Male Pin
- Contact Shape
- Square
- Mounting Type
- Through Hole
- Connector Type
- Header
- Fastening Type
- Detent Lock
- Number of Rows
- 1
- Pitch - Mating
- 0.049" (1.25mm)
- Voltage Rating
- 100V
- Contact Material
- Brass
- Insulation Color
Insulation Height0.169" (4.30mm) Base Product NumberM30-610 Insulation MaterialPolyamide (PA66), Nylon 6/6 Contact Length - Post0.091" (2.30mm) Current Rating (Amps)1A per Contact Operating Temperature-25°C ~ 85°C Mated Stacking Heights5.4mm Contact Finish - MatingTin Number of Positions LoadedAll Material Flammability RatingUL94 V-0 Contact Finish Thickness - Post- Contact Finish Thickness - Mating80.0µin (2.03µm)
