Request this MPN now. Sourcing more than one part? Upload your BOM and we can consolidate component sourcing into one quotation.
Description
Fan Tubeaxial 48VDC Square - 120mm L x 120mm H Ball 120.0 CFM (3.36m³/min) 2 Wire Leads
Specifications
- Mfr
- Orion Fans
- RPM
- 3100 RPM
- Noise
- 42.0dB(A)
- Width
- 25.00mm
- Series
- OD1225-IP69K
- Weight
- 0.341 lb (154.67 g)
- Air Flow
- 120.0 CFM (3.36m³/min)
- Fan Type
- Tubeaxial
- Features
- Auto Restart
- Packaging
- Box
- Part Status
- Active
- Termination
- 2 Wire Leads
- Bearing Type
- Ball
Approval AgencyCE, cURus, TUV, UR Static Pressure0.240 in H2O (59.8 Pa) Lifetime @ Temp.60000 Hrs @ 35°C Material - BladePolybutylene Terephthalate (PBT) Material - FramePolybutylene Terephthalate (PBT) Size / DimensionSquare - 120mm L x 120mm H Ingress ProtectionIP69K - Dust Tight, Water Resistant, Waterproof Base Product NumberOD1225 Current Rating (Amps)0.090A Operating Temperature-4 ~ 149°F (-20 ~ 65°C) Pricing tiers
| Packaging | Qty | Unit price |
|---|
| Box | 1 | ¥370.37000 |
| Box | 10 | ¥301.78000 |
| Box | 25 | ¥276.28120 |
| Box | 50 | ¥264.25320 |
