Description
15 Position Receptacle Connector 0.100" (2.54mm) Surface Mount, Right Angle Gold
Specifications
- Mfr
- Samtec Inc.
- Style
- Board to Board or Cable
- Series
- Tiger Claw™ SSM
- Features
- -
- Packaging
- Tube
- Part Status
- Discontinued at Digi-Key
- Termination
- Solder
- Applications
- -
- Contact Type
- Female Socket
- Contact Shape
- Square
- Mounting Type
- Surface Mount, Right Angle
- Connector Type
- Receptacle
- Fastening Type
- Push-Pull
Pitch - Mating0.100" (2.54mm) Voltage Rating405VAC, 572VDC Contact MaterialPhosphor Bronze Insulation Height0.125" (3.18mm) Base Product NumberSSM-115 Insulation MaterialLiquid Crystal Polymer (LCP) Current Rating (Amps)5.2A per Contact Operating Temperature-55°C ~ 125°C Contact Finish - MatingGold Number of Positions LoadedAll Material Flammability Rating- Contact Finish Thickness - Post- Contact Finish Thickness - Mating10.0µin (0.25µm) Pricing tiers
| Packaging | Qty | Unit price |
|---|
| Tube | 1 | ¥51.57000 |
| Tube | 10 | ¥46.09900 |
| Tube | 100 | ¥37.96740 |
| Tube | 500 | ¥30.01224 |
| Tube | 1,000 | ¥25.76348 |
| Tube | 5,000 | ¥23.50349 |
| Tube | 10,000 | ¥22.59951 |
