VTX-121-3015-415
PWR XFMR PCB ENCAP 1.5VA 2X115V
Manufacturer: VigortronixIC code: 5578-VTX-121-3015-415-ND
Request this MPN now. Sourcing more than one part? Upload your BOM and we can consolidate component sourcing into one quotation.
Description
Laminated Core 1.5VA Power Transformer 115V, 230V Primary Parallel 15V, Series 30V Secondary 50mA PCB
Specifications
- Type
- Laminated Core
- Series
- VTX-121-30xx-xxx
- Weight
- 0.419 lb (190 g)
- Packaging
- Bulk
- Center Tap
- No
- Part Status
- Active
- Power - Max
- 1.5VA
- Manufacturer
- Vigortronix
- Mounting Type
- PCB
- Size / Dimension
- 32.60mm L x 27.60mm W
- Termination Style
- PC Pin
- Voltage - Primary
- 115V, 230V
- Primary Winding(s)
- Dual
- Voltage - Isolation
- 4200Vrms
- Secondary Winding(s)
- Dual
- Height - Seated (Max)
- 24.00mm
- Current - Output (Max)
- 50mA
- Voltage - Secondary (Full Load)
- Parallel 15V, Series 30V
